Parameter
| Parameters | USR-SDR050-L | USR-SDR050 |
| Power interface | Terminal format,double power redundancy | |
| Net interface | 10/100Base-T | |
| MTBF | 100000 hours | |
| NO. Of the net port | 10/100M Ethernet port *5 | |
| Indicator light | PWR，Link/ACT | |
| Twisted-pair | 100m（CAT5E，CAT6） | |
| Input Voltage | DC 9-36V | DC 10-58V |
| Overall power Consumption | <3W | Normal <5W，POE<95W |
| Star topology | Support | |
| Bus topology | Support | |
| Tree topology | Support | |
| MAC address list | 1K | |
| Package buffer size | 448K | 512K |
| Forwarding delay | <3us | |
| Jumbo frame | Support 1536 | Support 2048bytes |
| Switching capacity | 1G | |
| Package forwarding rate | 0.744Mbps | |
| Shell | IP40 | |
| Power surge protection | IEC61000-4-5 Level 4（4KV/2KV）（8/20us） | IEC61000-4-5 Level 3（4KV/2KV）（8/20us） |
| Ethernet port surge protection | IEC61000-4-5 Level 3（4KV/2KV）（10/700us） | |
| EMI | CLASS A | |
| Anti- static | IEC61000-4-2 Level 4（8K/15K） | |
| Free-drop | 0.5m | |
| Work Temp | -40℃~+85℃ | |
| Storage Temp | -40℃~+85℃ | |
| Humidity | 5%~95% | |
| Heat dispatch | Fanless ,natural heat dissipation | |
| Size | 120*90*35.5 mm（L*W*H） | 143*104*48 mm（L*W*H） |
| Installation | DIN-Rail Mounting | |
| Shell material | Aluminum alloy+ sheet metal | Aluminum alloy |
| weight | 0.30 kg | 0.52 kg |
| Accessories | Device , terminal | Device, terminal, power supply |
Industrial Design
Wide running temp:-40-85℃，industrial lighting protection, anti-electrostatic,
Meet the requirement of different application scenes and make sure the stable and high speed.
Protection Class
Power IEC(level 4)
ESD (level 4)
Shell IP 40 to provide the invasion of solid objects
and make the product work normally.
More Functions of Industrial Ethernet Switches USR-SDR050-L
Support Wide Voltage Natural heat dissiption
Supports DC9-36V, provide more selection for Adopt fanless nature heat dissipation. do
user. The power interface is terminal format, not need any other extra device cooling
double power redundancy auxiliary which made it adopted to more environment
DIN-Rail Mounting
DIN-Rail Mountain, can be install and used
under the wall hanging scene.
Product Details
Intelligent transportation network transmission
Under the scene of the coal mine gas monitoring, the workers compose a while networking
monitoring solution by” switcher+serial server+terminal server” and maximize the cascade of
multiple sensors to protect the safety of underground workers.
Networking transmission in security field
Security monitoring used in the flexible environment, need several cameras working.
Mix the switcher and G router to enlarge the number of the net port, and take several cameras
into a TCP/IP to transport the videos. Networking quickly and meet the requirement.
