ST508E
ST508E
ST508E
Tiny-Size 5.8Ghz wireless bridge
Tiny-Size 5.8Ghz wireless bridge
Tiny-Size 5.8Ghz wireless bridge

Tiny-Size 5.8Ghz wireless bridge ST508E

Add to wishlist
Categories: , Tags: , , , Brand:

Description

Product Descripition

(Tiny-Size 5.8Ghz wireless bridge ST508E)

ST508E Wireless Bridge Overview

The ST508E is a high-performance, multi-purpose 5.8GHz wireless bridge powered by a Qualcomm core solution. With high TX power, durable hardware, and a built-in 8dBi directional antenna, it is an ideal choice for short-range transmissions. The device works best within 1 kilometer and can reach a maximum distance of 2 kilometers.

Applications and Use Cases

This wireless bridge is widely used in video surveillance scenarios such as agriculture, forestry, industry, commerce, transportation, tower crane, and elevator monitoring. Its stable performance makes it highly reliable in demanding environments.

Advanced iPoll 3 Technology

The ST508E integrates the iPoll 3 intelligent dynamic polling protocol based on TDMA technology. Well-known in the wireless industry, iPoll 3 ensures excellent anti-interference performance. Even in high-density and interference-heavy conditions, it delivers stable transmission and higher throughput.

QoS and Multi-Service Support

iPoll 3 optimizes wireless traffic with QoS priority support for DSCP mode under 802.1p. With four priority queues, the device can efficiently manage multiple services simultaneously.

Durability and Protection

The ST508E meets IP-64 waterproof standards and complies with industrial-grade requirements for temperature and humidity. Its 2kV surge resistance design provides strong protection in complex electrical environments, ensuring long-term reliability.

Best alternative to high cost wired


network transmissionThe wireless bridge products can connect two or more local area networks (LAN) together. They transmit network datas through wireless signals, allowing wireless communication between different LANs. Simply put, it transmits network datas and network video surveillance through wireless instead of network cables. Wireless bridge networking usually consists of two or more devices forming a point-to-point or point-to-multipoint network. In many network communication scenarios where wiring is difficult or the distance is too long, the flexible and low-cost wireless bridge solutions can effectively replace wired networks.
Wireless transmission in video surveillanceWireless transmission is used more and more widely in outdoor video surveillance, especially in park monitoring, construction site, dock monitoring, oil field, etc.
IPoll 3 intelligent polling wireless protocolThe wireless protocol based on TDMA technology can not only eliminate transmission congestion and self-interference generated in outdoor long-distance point-to-multipoint transmission , but also with the latest intelligent polling mechanism it groups the connected stations according to their activity. Stations that require less traffic are assigned to low-activity or idle groups and are allocated less airtime (fewer polling times) while requiring greater traffic stations are assigned to active groups and allocated more airtime (more polling times). By reducing the total number of times of polling the stations, lower latency and higher total throughput are achieved. Even in point-to-multipoint scenario of 1 to 64 or more , the overall network efficiency will not significantly decrease.
Multicast enhancementThe multicast optimization function allows multicast traffic to be sent only to terminals in need, avoiding the waste of network resources.
Advanced QoS
  • QoS in iPoll 3 supports transmitting pre-marked data according to priority.
  • QoS (L2/L3 or DSCP/COS) – supports different priority traffic types (must be implemented with switches that support corresponding functional mechanisms)
  • Providing 4 queue priorities for different services (best effort , background , video , voice)
  • Strict policy based
  • Supports multiple services (data , voice , video, etc.)
Professional graphical user interfaceThe device management GUI is based on HTML 5 technology, which is responsive, easy to configure, and adaptable to computer browsers and mobile browsers.
Rich frequency band + non-standard channels +
multiple bandwidthsSupporting 4.9Ghz~6.1 Ghz ultra-wide frequency band. Providing much more options for channel planning and avoiding occupied channels. Supporting multiple bandwidths of 5Mhz/10Mhz/20Mhz/40Mhz. Providing greater flexibility for transmission distance/capacity/interference avoidance. The narrower the bandwidth, the longer the transmission distance, the stronger the anti-interference, the lower the throughput; the wider the bandwidth, the shorter the transmission distance, the weaker the anti-interference, and the higher throughput. Supporting non-standard channels. Non-standard channels have 5MHz channel step and allow users to select center frequencies will not be valid with 802.11 specification, bringing more possibilities for channel planning and interference avoidance.
Note: Please comply with local laws and regulations when selecting the corresponding channel.

Built-in rich and useful tool set

  • Site survey
  • Spectrum Analyzer
  • Antenna alignment
  • Link test
  • Ping & Traceroute
    With the tools users can easily and efficiently deploy and troubleshoot without resorting to third-party tools.
Tiny-Size 5.8Ghz wireless bridge ST508E
Network topology1. Point-to-point
Network topology2. Point-to-multipoint
Network topology3. Multi-hop transmission
4. Hybrid networking (point-to-point + point-to-multipoint)

Application scenario

  • Emergency communications
  • Park video surveillance
  • Forest fire prevention
  • Wireless broadband
  • Power plant
  • Environmental monitoring
  • Construction tower crane
  • Mine site
  • Elevator video surveillance
